complete with rear conveyor, with fittings, with electric equipment, with three safety devices and with all electric motors.


  • Very robust portable structure formed by sides of cast iron joined by steel girders.
  • Slicker cylinder of large diameter in treated steel of high quality, fitted on self-aligning roller bearings.
  • Electronic balancing of the slicker cylinder before and after the fitting of the slickers.
  • Slickers in stainless steel AISI 316 for a long life of the edge.
  • Supporting cylinder covered by antioil rubber, hardness as required by the customer.
  • Stainless steel transport cylinder with symmetrical groove.
  • Double washing device of the transport cylinder to ensure the complete cleaning and consequently the transport efficiency.
  • Automatic water supply on working area only with closed machine.
  • Hydraulic control transport with continuous adjustable speed from 30 to 54 m/1'.
  • Hydraulic transport inversion device taking on the most difficult parts of the hide without having to open the machine for a second feed-in.
  • Hydraulic control for opening and closing the machine with adjustable limit stop shock absorbers.
  • Opening-closing pedal adjustable either for sensitive action of for stable controls.
  • Decimal adjustment of the thickness.
  • Control members for the opening and closing located on the exterior of the machine in a position which is protected from the water and rotating on anti-friction bearings.
  • Barrier safety device over the whole face of the machine.
  • Second infrared safety device.
  • Sliding case of slicker cylinder to eliminate the risk of accidental contact with the hands
  • Electric equipment incorporated in waterproof locker with auxiliary voltage of 24 Volts conforming to the international security standards.
LWorking width mm 1600
Power of main motor HP(Kw) 10 (7,5)
Pump motor power HP(Kw) 4 (3)
Power of conveyor motor HP(Kw) 2 (1,5)
Conveyor working length mm 2500
Floor space mm 3650x3000
Net weight Kg 2700
Gross weight with seapackage Kg 3250
Volume with seapackage m3 (mm) 14 (3700x1750xH2150)
